The Paprsky Hydraulic Punching Machine series provides high-speed, precision metalworking tools designed to create clean, burr-free holes significantly faster than traditional drilling methods. Engineered to operate via an external hydraulic pump, these units can be easily deployed for on-site operations where electrical power may be unavailable. Available in two configurations (PS-CH-60 and PS-CH-70), they offer scalable solutions for varying material thicknesses and deep throat requirements.
Specifications
| Model | Output |
Aperture |
mm |
Deep throat | Weight |
| PS-CH-60 | 31T | φ10.5- φ20.5 | Copper & aluminum 10 | 95mm | 13.5kg |
| PS-CH-70 | 31T | φ10.5- φ20.5 | Copper & aluminum 12 | 110mm | 28kg |
Key Features
- High-Speed Operation: Completes a punch in just a few seconds, drastically outperforming standard drill speeds and increasing overall productivity.
- Burr-Free Finish: The hydraulic shearing action produces perfectly clean holes, eliminating the need for secondary deburring or filing.
- Offset Prevention: Both models feature a specialized pressing mechanism design that ensures punching precision is maintained without the die slipping or offsetting during operation.
- Stable & Portable: The 13.5 kg PS-CH-60 offers excellent portability, while the 28 kg PS-CH-70 provides a heavier, highly stable platform for thicker industrial metals.
Applications
- Busbar Fabrication: Ideal for punching precise connection holes in thick copper and aluminum busbars used in electrical switchgears and distribution panels.
- On-Site Construction: Perfect for remote field operations where quick, precise metal punching is required without access to electrical outlets.
- Heavy Manufacturing: Used in metal workshops and industrial fabrication to rapidly prepare conductive metals for heavy assembly.
