Product Description
The Paprsky Protecting Tackle with Three Wheels (PS-SH Series) is a heavy-duty cable guiding system designed to protect large diameter cables during installation. This specialized tackle features a three-wheel configuration that creates a smooth, large-radius curve, significantly reducing friction and preventing damage to the cable's outer sheath as it is pulled around corners or through complex pathways.
Engineered for high-capacity cable laying projects, the PS-SH series ensures that cables maintain a safe bending radius of R450mm. With pulley specifications ranging from φ80mm to φ200mm, this robust equipment is essential for preserving the integrity of power and telecommunication cables in demanding industrial environments.
PROTECTING TACKLE WITH THREE WHEELS
| Model |
Pulley specifications |
Bending radius | Weight |
| PS-SH50-3 | φ80mm | R450mm | 17kg |
| PS-SH90-3 | φ90mm | R450mm | 18kg |
| PS-SH100-3 | φ100mm | R450mm | 20kg |
| PS-SH130-3 | φ130mm | R450mm | 21kg |
| PS-SH150-3 | φ150mm | R450mm | 22kg |
| PS-SH180-3 | φ180mm | R450mm | 24kg |
| PS-SH200-3 | φ200mm | R450mm | 26kg |
Key Features
- Cable Protection: Three-wheel design distributes pressure and prevents kinking or abrasion.
- Large Bending Radius: Maintains a safe R450mm radius, crucial for high-voltage and fiber optic cables.
- Smooth Operation: High-quality rollers ensure low friction during cable pulling.
- Robust Build: Heavy weight and solid construction provide stability during operation.
- Versatile Sizing: Available in multiple pulley sizes to accommodate different cable diameters.
Applications
- Underground Cabling: Guiding cables into ducts and manholes.
- Power Plants: Routing heavy power cables through facility infrastructure.
- Industrial Sites: Managing complex cable runs in factories and refineries.
- Telecommunications: Protecting fiber optic bundles during installation.
Brand Value Proposition
Paprsky Energy is dedicated to safeguarding your infrastructure investments. Our Protecting Tackle with Three Wheels is engineered to provide maximum protection for your cables, ensuring a damage-free installation process that extends the lifespan of your electrical and communication networks.
