The Paprsky H-Type Terminal Block is a highly reliable and durable wiring solution designed to facilitate secure, multi-pole electrical connections. Manufactured from premium PA (Polyamide), PE (Polyethylene), or PP (Polypropylene) materials, this terminal block provides excellent electrical insulation, robust heat resistance, and long-lasting mechanical strength. Its compact H-Type configuration makes it especially suitable for dense wiring layouts in space-limited enclosures, ensuring stable conductivity for control panels, industrial equipment, and household electrical systems. The secure clamping structure firmly grips wires to prevent loosening or dangerous arc formation, making it a staple for maintenance and new installations alike.
Specifications
- TERMINAL BLOCK H TYPE
- Material: Made from PA, PE, or PP.
|
Product Name |
LENGTH | WIDTH | HEIGHT | A | B | mm^2 | VOLT | AMP |
| TB-PS-3A | 92.9 | 15.8 | 12.8 | 5.8 | 7.9 | 4 | 400V | 3A |
| TB-PS-6A | 107.9 | 15.4 | 13.8 | 6.3 | 9.2 | 6 | 400V | 6A |
| TB-PS-10A | 120.5 | 19.9 | 16.4 | 8.2 | 10.2 | 10 | 400V | 10A |
| TB-PS--16A | 137.8 | 22.9 | 18.0 | 9.9 | 11.9 | 12 | 400V | 16A |
| TB-PS-30A | 166.5 | 25.8 | 20.1 | 10.8 | 14.1 | 14 | 400V | 20A |
| TB-PS-60A | 190.5 | 29.6 | 24.9 | 13.2 | 16.2 | 16 | 400V | 30A |
Key Features
- Premium Insulation: Constructed from high-quality PA/PE/PP materials, providing exceptional electrical insulation and resistance to heat and mechanical wear.
- Secure Wire Clamping: Features a robust internal clamping structure that holds wires firmly in place, significantly reducing the risk of loosening or arc formation under load or vibration.
- Compact H-Type Profile: The streamlined, multi-pole design is optimized for dense wiring layouts and space-constrained electrical enclosures.
- Stable Conductivity: Equipped with corrosion-resistant metal inserts that ensure a consistent, low-resistance connection for a long operational lifespan.
Applications
- Multi-wire organization inside electrical distribution boards and residential wiring terminals.
- Reliable power routing for HVAC units, control boxes, and small to medium machinery.
- Safe and insulated connections for light fixtures, power outlets, and household appliances.
- Professional termination solutions for complex industrial control panels.
